Air Jet Mill Classifier Wheel Speed Adjustment: Key Points for Particle Size Distribution Control

Air jet milling is a widely used technology in the pharmaceutical, chemical, and materials industries for producing ultrafine powders with tightly controlled particle sizes. One of the most critical parameters in this process is the rotational speed of the classifier wheel, which directly determines the particle size distribution (PSD) of the final product.

What Is an Air Jet Mill?

An air jet mill uses high-pressure compressed air to create a vortex in the grinding chamber, where particles collide at high speeds and are reduced in size without mechanical contact. A classifier wheel, located at the outlet of the chamber, sorts particles based on size — only particles smaller than a set threshold can pass through.

The Role of the Classifier Wheel

The classifier wheel acts as a centrifugal sieve:

• Fast rotation = finer cut point: Higher speed creates stronger centrifugal force, allowing only smaller particles to pass through.

• Slow rotation = coarser product: Larger particles can escape as the separation threshold becomes less strict.

Thus, adjusting the classifier wheel speed is an effective way to fine-tune the particle size distribution.

Key Points in Speed Adjustment for PSD Control

1. Understand the Target Particle Size Range

Before setting the classifier speed, it’s essential to define:

• D90 (90% of particles below this size)

• D50 (median particle size)

• Application-specific requirements (e.g., inhalation APIs, battery materials, pigments)

2. Balance Between Fineness and Yield

Higher classifier speeds improve fineness but may:

• Reduce throughput

• Increase energy consumption

• Lead to product loss due to over-classification

Lower speeds improve yield but risk insufficient fineness.

3. Avoid Abrupt Speed Changes

Gradual speed adjustments allow for:

• Stable flow inside the mill

• Consistent particle trajectory

• Reduced risk of system imbalance or overloading

4. Synchronize With Airflow and Feed Rate

Classifier speed should be adjusted in coordination with:

• Nozzle pressure

• Air volume (CFM)

• Material feed rate

For example, increasing classifier speed without adjusting airflow may disrupt the separation dynamics.

5. Monitor Real-Time Particle Size

Install online PSD analyzers or use laser diffraction equipment for feedback control. This enables:

• Closed-loop control systems

• Automatic adjustment of classifier RPM

• Improved batch-to-batch consistency

Practical Example

A pharmaceutical company aiming for D90 < 5 μm for an API:

• Starts with a classifier speed of 3500 RPM

• Observes particles at D90 = 6 μm

• Increases speed to 4000 RPM, achieving the desired D90 = 4.8 μm

• Then optimizes feed rate to maintain yield and prevent overload

This iterative adjustment ensures the PSD remains within specification.

Conclusion

In air jet milling, classifier wheel speed is a powerful control knob for tailoring particle size distribution. By carefully adjusting this parameter in harmony with airflow and feed rate, manufacturers can achieve optimal product quality and process efficiency. As demand for high-precision powders continues to grow, intelligent control of classifier dynamics will play an increasingly important role in advanced manufacturing.
